Learn how to implement distance calculation
In our previous blog, we helped you with the integration of Bing Maps API with Dynamics 365 CRM application and creation of Auto Suggestion functionality on the address field. With this blog, we will guide you on how to calculate the distance between a source and the destination address.
Distance Calculation from Source to Destination Address Field into Dynamics 365 CRM
Step 1: Create a web resource name it as Source Web Resource and place all the above code into it. Our Source Web resource will remain the same and will not change.
Step 2: Create another web resource and name it as Destination Web Resource and place the below code:
<html>
<head>
<title>
autosuggestuiwithoutmapHTML</title>
<meta http-equiv=”Content-Type” content=”text/html; charset=utf-8″>
<style type=”text/css”>
body { margin: 0; padding: 0; overflow: hidden; font-family: ‘Segoe UI’, Helvetica, Arial, Sans-Serif } </style>
</head>
<body style=”overflow-wrap: break-word;” onfocusout=”parent.setEmailRange();”>
<div id=”searchBoxContainer”>
<label style=”display: inline-block; max-width: 100%;margin-bottom: 5px;font-weight: bold;color: #666;” for=”Search”>
To Address</label>
<br>
<input id=”searchBox” style=”display: block;width: 450px;height: 35px;font-size: 15px;line-height: 1.42857; color: rgb(85, 85, 85);background-color: rgb(255, 255, 255);background-image: none; border: 1px solid rgb(204, 204, 204);border-radius: 0px;box-shadow: rgba(0, 0, 0, 0.075) 0px 1px 1px inset; transition: border-color 0.15s ease-in-out 0s, box-shadow 0.15s ease-in-out 0s;box-sizing:content-box;/* padding: 10px; */padding-left: 12px;” type=”text” placeholder=”Search your address here…” autocomplete=”off”>
</div>
<script type=”text/javascript”>
function setClientApiContext(formContext) { // Optionally set Xrm and formContext as global variables on the page. window._formContext = formContext; } function loadMapScenario() { Microsoft.Maps.loadModule(‘Microsoft.Maps.AutoSuggest’, { callback: onLoad, errorCallback: onError }); function onLoad() { var options = { maxResults: 5 }; var manager = new Microsoft.Maps.AutosuggestManager(options); manager.attachAutosuggest(‘#searchBox’, ‘#searchBoxContainer’, selectedSuggestion); } function onError(message) { document.getElementById(‘printoutPanel’).innerHTML = message; } function selectedSuggestion(suggestionResult) { _formContext.getAttribute(“crm-deststreet”).setValue(suggestionResult.address.addressLine); _formContext.getAttribute(“crm-destcity”).setValue(suggestionResult.address.locality); _formContext.getAttribute(“crm-destpostalcode”).setValue(suggestionResult.address.postalCode); _formContext.getAttribute(“crm-deststateorprovince”).setValue(suggestionResult.address.adminDistrict); _formContext.getAttribute(“crm-destcountry”).setValue(suggestionResult.address.countryRegion); var concatDestinationAddress = suggestionResult.address.addressLine + ‘,’ + suggestionResult.address.locality + ‘,’ + suggestionResult.address.adminDistrict + ‘,’ + suggestionResult.address.countryRegion; var sourceAddressLine = _formContext.getAttribute(“crm-srcstreet”).getValue(); var sourceAddressCity = _formContext.getAttribute(“crm-srccity”).getValue(); var sourceAddressState = _formContext.getAttribute(“crm-srcstate”).getValue(); var sourceAddressCountry = _formContext.getAttribute(“crm-srccountry “).getValue(); var concatSourceAddress = sourceAddressLine + ‘,’ + sourceAddressCity + ‘,’ + sourceAddressState + ‘,’ + sourceAddressCountry; map = new Microsoft.Maps.Map(‘#myMap’, {}); //Load the directions module. Microsoft.Maps.loadModule(‘Microsoft.Maps.Directions’, function () { //Create an instance of the directions manager. directionsManager = new Microsoft.Maps.Directions.DirectionsManager(map); //Create waypoints to route between. var sourceWayPoint = new Microsoft.Maps.Directions.Waypoint({ address: concatSourceAddress }); directionsManager.addWaypoint(sourceWayPoint); var destinationWayPoint = new Microsoft.Maps.Directions.Waypoint({ address: concatDestinationAddress }); directionsManager.addWaypoint(destinationWayPoint); //Add event handlers to directions manager. Microsoft.Maps.Events.addHandler(directionsManager, ‘directionsError’, directionsError); Microsoft.Maps.Events.addHandler(directionsManager, ‘directionsUpdated’, directionsUpdated); //Calculate directions. directionsManager.calculateDirections(); }); } function directionsUpdated(e) { //Get the current route index. var routeIdx = directionsManager.getRequestOptions().routeIndex; //Get the distance of the route, rounded to 2 decimal places. var distance = Math.round(e.routeSummary[routeIdx].distance * 100) / 100; //Get the distance units used to calculate the route. var units = directionsManager.getRequestOptions().distanceUnit; var distanceUnits = “; if (units == Microsoft.Maps.Directions.DistanceUnit.km) { distanceUnits = ‘km’ } else { //Must be in miles distanceUnits = ‘miles’ } } function directionsError(e) { alert(‘Error: ‘ + e.message + ‘\r\nResponse Code: ‘ + e.responseCode) } } </script>
<script src=”https://www.bing.com/api/maps/mapcontrol?key={Your Bing Maps API Key} &callback=loadMapScenario” defer=”” type=”text/javascript” async=””>
</script>
<div id=”myMap” style=”position:relative;width:500px;height:500px;display:none;”>
</div>
<div id=”directionsItinerary”>
</div>
</body>
</html>
Step 3: Almost all the above code is the same as explained earlier with some of the additions. Major additional code comes under selectedSuggestions function where we are getting source address field values into our destination address web resource and concatenating all the field values to form full address.
var concatSourceAddress = sourceAddressLine+’,’+sourceAddressCity+’,’+sourceAddressState+’,’+sourceAddressCountry;
Step 4: The most important step is where we are using Microsoft.Maps.Directions.DirectionsManager API and creating the object of it. Also, we are creating an object of Microsoft.Maps.Directions.Waypoint to provide sourceWaypoint and destinationWaypoint and pass our source address and destination address.
We are getting source address from CRM fields through the execution context while the destination address is from the (current) web resource autosuggestion address field.
Step 5: In the below section of the code, we are finally getting distance from the source to the destination address.
function directionsUpdated(e)
{
//Get the current route index.
var routeIdx = directionsManager.getRequestOptions().routeIndex;
//Get the distance of the route, rounded to 2 decimal places.
var distance = Math.round(e.routeSummary[routeIdx].distance * 100)/100;
//Get the distance units used to calculate the route.
var units = directionsManager.getRequestOptions().distanceUnit;
var distanceUnits = ”;
if (units == Microsoft.Maps.Directions.DistanceUnit.km)
{
distanceUnits = ‘km’
}
else
{
//Must be in miles
distanceUnits = ‘miles’
}
}
Here, we are creating a new function name directionsUpdated to get the shortest route index and distance using DirectionsManager.getRequestOptions AP. We can just display this distance using an alert field or store this value into the CRM Distance field by using _formContext global variable.
Provide Bing Maps API key in the highlighted section while keeping the rest of the code the same. It’s already been explained earlier in the blog.
Step 6: Similarly create JavaScript function to pass executioncontext object into our source as well as destination web resource created and place this Jscript function onload of that form.
Similarly, place both the web resources created into any entity form where you want distance functionality as shown above and finally Save and Publish.
Conclusion
In this blog, we went through the integration of Distance Calculation with just a few lines of code. Layering your CRM with Bing Maps will enable you to map your sales, accounts, leads, opportunities based on customer demographics lending you an unparalleled competitive edge in the market.
Want to integrate location intelligence in your CRM? Contact our experts for a tailored demo.
Ready to enhance Dynamics 365 with location intelligence?
Integrate Bing Maps with Dynamics 365 to track, optimize, and manage distances more effectively – powered by Alphavima’s implementation expertise.
FAQs
What is the purpose of Bing Maps API integration in Dynamics 365 CRM?
Integrating Bing Maps API into Dynamics 365 CRM enables distance calculation between a source and destination address directly within the CRM. This helps in route optimization, territory planning, and enhancing sales and service operations.
Can I calculate distance between two addresses in Dynamics 365?
Yes. By using Bing Maps DirectionsManager API and JavaScript, you can calculate the distance (in kilometers or miles) between two address fields in Dynamics 365 and display or store it as a custom field.
What are the main steps to set up Bing Maps distance calculation?
The blog outlines:
Creating two web resources (source and destination address)
Writing and deploying JavaScript to calculate distance using Bing Maps API
Embedding this logic in a CRM form to trigger calculation and display results
Is coding required to integrate Bing Maps with Dynamics 365?
Yes. Basic JavaScript knowledge is required to write functions that call Bing Maps services, handle user input, and update the CRM UI. However, the blog provides ready-to-use code for implementation.
What CRM entities support distance calculation using Bing Maps?
You can implement this on any Dynamics 365 entity with address fields - such as Leads, Accounts, Opportunities, or custom entities-where geographic proximity is relevant.
What does the Bing Maps API return in this integration?
The API returns:
A calculated distance between two geographic points
The route information
Units (km or miles), which can be displayed or stored in a CRM field
How do I get a Bing Maps API key?
You can obtain a Bing Maps API key by registering for the Bing Maps Dev Center via Microsoft. The key is then embedded into your JavaScript snippet to authenticate API requests.
Is this integration secure?
Yes. Bing Maps API uses HTTPS and Microsoft's standard security practices. The data is processed through client-side scripts within CRM and is not stored externally unless explicitly programmed.
Can I use this integration for mobile CRM users?
Yes. As long as the CRM form is mobile-enabled and the custom JavaScript functions are compatible, mobile users can access distance calculation functionality within Dynamics 365 on the go.
